Statistics of station Moi

Here you can find statistics of the TOA lightning detection station Moi.

  • Id: 1568
  • Firmware: 0.0
  • Controller: 19.3
  • Amplifier: H0 / E0
  • Antenn 1+2: Ferrite rod
  • Antenn 3: Electric field
  • Comment: System Blue with an E-field antenna and two ferrite rod antennas

General statistics of the last hour

  • Station aktiv: Ja / ingen mottagning
  • Senast uppdaterad: 16.1 minuter sedan
  • Last detected stroke: 2022-06-22 23:53:36 UTC
  • Blixtar: 0
  • Signaler: 0
  • Andel lokaliserat: -
  • Andel blixtar: 0.0% (Karta)
  • "Egna" blixtar (13-18 stationer): 0 (0.0%)

Last signal

Shows one of the latest signals which the station did send to the server.

Antal blixtar

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Moi and the mean stroke count for all stations

Grafer: Blixtstatistik

Antal signaler

The count of received signals per hour of the station Moi and also mean value of all stations.

Grafer: Signalstatistik


Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Grafer: Lokaliserings- och blixtandel

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Grafer: Stroke ratio by distance

Riktning till blixtar

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Grafer: Stroke ratio by bearing
