Statistics of station Bogota D.C.

Here you can find statistics of the TOA lightning detection station Bogota D.C..

  • Id: 2581
  • Firmware: 0.0
  • Controller: 19.5
  • Amplifier: H1 / E1
  • Antenna 1: Ferrite rod, length=200mm
  • Antenna 2+3: Ferrite rod, length=200mm, shielded
  • Antenna 4: Electric field, length=300mm, shielded
  • Comment: JERM-EMC-UN [3.1] getting ready...

General statistics of the last hour

  • Station active: no
  • Last active: 1,709,674.2 minutes ago
  • Last update: 14.0 minutes ago
  • Last detected stroke: 2021-08-06 16:54:10 UTC
  • Last signal: 2021-10-27 17:59:01 UTC

Stroke count

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Bogota D.C. and the mean stroke count for all stations

Graphs: Stroke statistics

Signal count

The count of received signals per hour of the station Bogota D.C. and also mean value of all stations.

Graphs: Signal statistics

Ratios

Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Graphs: Locating and stroke ratios

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Graphs: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Graphs: Stroke ratio by bearing
