Statistics of station Ramsey

Here you can find statistics of the TOA lightning detection station Ramsey.

  • Id: 1228
  • Firmware: 1.7
  • Controller: 10.4
  • Amplifier: 12.3
  • Antenna 1+2: Ferrite rod, length=200mm, shielded
  • Comment: RED, optimizing gain/trigger settings

General statistics of the last hour

  • Station active: no
  • Last active: Never before
  • Last update: 9.2 minutes ago
  • Last detected stroke: None
  • Last signal: -

Stroke count

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Ramsey and the mean stroke count for all stations

Graphs: Stroke statistics

Signal count

The count of received signals per hour of the station Ramsey and also mean value of all stations.

Graphs: Signal statistics

Ratios

Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Graphs: Locating and stroke ratios

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Graphs: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Graphs: Stroke ratio by bearing
