Statistics of station Seeheim-Jugenheim,Hessen [BLUE]

Here you can find statistics of the TOA lightning detection station Seeheim-Jugenheim,Hessen [BLUE].

  • Id: 2137
  • Firmware: 0.0
  • Controller: 19.4
  • Amplifier: H0 / E0
  • Antenna 1: Ferrite rod, length=600mm, diameter=30mm, shielded
  • Antenna 2: Ferrite rod, length=300mm, diameter=20mm, shielded
  • Antenna 3: Loop, diameter=700mm, windings=13, shielded, transformer
  • Antenna 4: Electric field, length=2000mm
  • Comment: Ferrit /Loop Antenna Test
  • Other Stations from this User: 2137

General statistics of the last hour

  • Station active: no
  • Last active: 9,715.8 minutes ago
  • Last update: 13.0 minutes ago
  • Last detected stroke: 2024-07-05 15:28:49 UTC

Stroke count

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Seeheim-Jugenheim,Hessen [BLUE] and the mean stroke count for all stations

Graphs: Stroke statistics

Signal count

The count of received signals per hour of the station Seeheim-Jugenheim,Hessen [BLUE] and also mean value of all stations.

Graphs: Signal statistics


Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Graphs: Locating and stroke ratios

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Graphs: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Graphs: Stroke ratio by bearing
