Statistics of station E-29469 Calahonda/Mijas-Costa

Here you can find statistics of the TOA lightning detection station E-29469 Calahonda/Mijas-Costa.

  • Id: 1424
  • Firmware: 0.0
  • Controller: 19.1
  • Amplifier: H1 / E1
  • Antenna 1+2: Ferrite rod, length=180mm, shielded, transformer
  • Antenna 3: Ferrite rod, length=120mm, shielded, transformer
  • Antenna 4: Loop, diameter=750mm, transformer
  • Comment: BLUE-bd.|PCB19.1/H1/E1|fw8.1b1

General statistics of the last hour

  • Station active: nem
  • Last active: Soha nem
  • Last update: 8,1 minutes ago
  • Last detected stroke: None
  • Last signal: -

Stroke count

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station E-29469 Calahonda/Mijas-Costa and the mean stroke count for all stations

Grafikonok: Stroke statistics

Signal count

The count of received signals per hour of the station E-29469 Calahonda/Mijas-Costa and also mean value of all stations.

Grafikonok: Signal statistics


Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Grafikonok: Locating and stroke ratios

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Grafikonok: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Grafikonok: Stroke ratio by bearing
